Colorimeter Color Difference Test Meter 8MM Digital Precise Color Analyzer Coating Printing Testing Device with D65 D50 F11 C Light Source

Features Two languages to switch, buttons and menus operation are easy to control A variety of light and color space models meet special needs of different measurement conditions Two calibrations: white calibration and zero calibration, the measurement data are more accurate and stable 1500 sets of data storage space, can check. callout. upload the data at any time Professional color quality software would assist the color analysis and quality control Technical Specifications Illuminant/light system:45/0 Measuring aperture:Ø8mm Display model:L*a*b*、L*C*H*、XYZ、∆E*ab、∆（L*a*b*）、∆（L*C*H*）、∆ ∆XYZ Operating language:Simplified Chinese, Traditional Chinese, English Storage space:Standard: 50 sets, 30 sets color difference data under a standard data. Standard illuminant:D65, D50, F11, C Calibration:White calibration, Zero calibration Repeatability:Standard deviation:within △E*ab≤0.08 ( When the white calibration plates is measured 30 times, and averaged) Weight: 330g Size: 110 ×60 ×190mm Scope of application Color matching in injection and quality control in production process Color-difference detection and color-difference batch control in printing process Color-difference analysis of spray paint surface and electroplate surface Color-difference of different areas of the metal treating surface Quality control in color difference in sample and the standard Color difference inspection of batch products in outdoors On-line monitoring of color difference in production process

• ❤❤(1)【Application】 Widely used in the color management field of plastics, printing, paint, ink, textile, printing and dyeing garments, etc. It can measure monochrome and surface flat samples. According to the Lab, Lch principle of CIE color space, the measurement shows that the sample is tested. The color difference E and the Lab value of the sample. Suitable for internal and external color evaluation and data management.
• ❤❤(2)【Automatic calibration】It is necessary to test the standard first, and save the value of the standard, and then test the sample. At this time, the L*, a*, b* values of the standard and the sample are displayed on the screen, and the L*,a*,b*,E* value are automatically calculated. The colorimeter will judge whether the sample is qualified according to the set color difference range. The measurement data is accurate and reliable.
• ❤❤(3)【USB、Printer、Power Ports】The colorimeter has three ports: USB port, which can be connected to the computer for advanced settings and download data report (USB driver needs to be installed when connecting for the first time), micro printer socket, only when the micro-printer is connected in the test interface. In order to print the current data. The power socket can be connected to a power outlet when the battery is dead.
• ❤❤(4)【Features】can store 50 sets of standard samples and 30 sets of sample color difference, switch between English, Simplified Chinese and Traditional Chinese, and measurement accuracy higher. The machine can be calibrated before use.
• ❤❤(5)【Instructions】We provide a full set of operating videos and instruction manuals, please feel free to contact us if you have any questions. We will answer your questions.
